Exhaust Gas Analyzer (CO/HC)


  • Outstanding accuracy, stability and durability
  • NDIR technology for reliable
  • Need less than 5 minutes of warm-up for quick inspection preparation
  • Convenient key operating system
  • Portable(compact size, light weight)
  • Built-In Printer /  RS232 PC Program
Measurement items
CO,  HC
Measurement principleCO, HC

Nondispersive infrared sensor (NDIR)

Measuring rangeCO0.00 ~ 10.00%
HC0 ~ 9,999ppm
Response time
Max.10sec (over90%)
Preheating time
5 minutes
Size
245(W) x 380(D) x 155(H) mm
Weight
About 5 kg (Main body)
Power
100~220V Free Voltage(50W)
